Botron B32250 ESD 3-Layer Rubber Mat Roll, 2' x 50', Green, .12" Thick

Botron's Type T3 ESD rubber table mats feature a three layer design which provides excellent electricals and high durability. This ESD rubber mat combines the durability of a conventional rubber ESD mat with the ergonomics of a foam three layer mat. These mats will not curl and are guaranteed to lay flat on the worksurface. Moisture-lock technology helps prevent the mat from drying out, cracking, shrinking and elongation.

• 3-Layer construction features an inner foam layer that supports stress absorption for accidental drops
• Solder resistant surface
• UV resistant color stability and conductivity
• Reversible from dissipative to condutive
• Chemical and abrasion resistant
• Lead-Free RoHS compliant

Technical Specifications

• .12" thick rubber construction
• Top Layer: Dissipative 10e8
• Bottom Layer: Conductive 10e4
• RTT: 5.8x10e7 - 6x10e8
• RTG: 5.2x10e7 - 5x10e8
• Charge decay: 5000 volts to 50v-<0.01 seconds
• Meets ANSI/ESD S4.1, ANSI/ESD S7.1, ESD TR53
